COMPACT Pro 820 LED grow light

Product information

LED 1:1 replacement for HPS

Reviews

4.33 out of 5 stars

£799.00£899.00

COMPACT Pro 820 model stands out for its super compact size compared to the power it delivers. With a maximum PPF of 2000 μmol/s, 2.5 μmol/j efficacy, and lower heat emission than HPS grow light, it is the top choice for 1:1 HPS replacement.

Find where to buy

Features

  • Plug & Play - takes no time to install
  • 1:1 HPS replacement
  • Super compact design
  • Higher specs Seoul, San'an & Osram LED chips
  • Full-spectrum light output
  • Supports 0-10V controllers
  • Coverage area up to 1.5 x 1.5 m

Package includes

LED LIGHT FIXTURE
1 unit
AC POWER CORD
1 piece (3m / 10ft)
RJ CABLE
1 piece
'V' HANGER
1 piece

Technical specifications

MAX POWER
820W
INPUT VOLTAGE
220-240V
DIMMING
0-10V Dimmable or knob
MAX PPF
2000 μmol/s
EFFICACY
2.5 μmol/j
MAX AMBIENT TEMPERATURE
40°C / 104°F
BEAM ANGLE
120°
LED CHIPS
Seoul (white), San'an (blue) & Osram (red)

General specifications

DIMENSIONS (L.W.H)
740 x 340 x 90 mm / 29 x 13.5 x 3.5 in
GROSS WEIGHT
16.5 kg / 36 lbs
NET WEIGHT
14.5 kg / 31.9 lbs
WARRANTY
5 years
Download specs sheet Manual

Horticulture LED grow lights became the top choice for growers due to their efficiency, power, low heat, and longevity. NŌKOTECH offers a wide range of LED lights for home and industrial growers.

Compact Pro 820 LED grow lights

COMPACT Pro 820 full-spectrum LED grow light is the top choice for a 1:1 HPS replacement as it seamlessly fits into existing 1000W HPS layouts. It emits more heat than other ordinary LED grow lights, therefore, this fixture is perfect for mid-cold regions to help control the grow room temperature.

CONNECTIVITY AND CONTROL

Using RJ ports and a 0-10V controller COMPACT Pro 820 can be joined to a daisy chain. This way it’s possible to connect up to 80 fixtures on one chain. Most of the 0-10V controllers support 2 chains. We suggest using our touchscreen SMART controller. Additionally, this model seamlessly integrates with TrolMaster controllers through their specialized adapter, the LMA-14.

COMPACT SIZE and POWER

This model stands out for its super small size compared to the power it delivers. With a maximum PPF of 2000 μmol/s, 2.5 μmol/j efficacy, and higher heat emission than ordinary LED grow light, it is the top choice for 1:1 HPS replacement. Moreover, COMPACT Pro 820 is straightforward to install – just plug & play.

With a 120° beam angle, the COMPACT Pro 820 fixture will provide more than 700 average PPFD of PAR light intensity across your plants at 90cm (35in) height from the canopy.

COMPACT Pro 820 grow light PPFD distribution

This fixture is for indoor use only (climate-controlled indoor farms and grow rooms). The full-spectrum output for these fixtures is specially designed for any scale horticulture cultivation, from propagation and cloning to your crops’ vegetative growth and blooming stages.

Compact Pro 820 fixture spectrum output

COMPACT Pro 820 fixture uses high quality very efficient Seoul 5050 6500k (white), San’an 450nm (blue), and Osram 660nm (red) diodes to create a balanced full spectrum light best suitable for photosynthesis.
